1. High efficiency, 1.0s-1.2s/s screw; can completely replace manual screw fastening; 2. High cost-effectiveness, strong versatility; can store screw coordinates for multiple products; 3. Stable and reliable; easy to learn and use, dedicated screw machine control system; 4. Abnormal alarm function.
Material handling method: Vacuum suction Frame: Aluminum alloy Number of electric screwdrivers: 1 PC Number of feeders: 1 PC Number of worktables: 1 PC Holders: Customized Air source: 0.4-0.8MPa, oil-free, dry Power supply: 220V 50Hz Power: 200W Efficiency: 1.0s-1.2s/screw Applicable screws: <M2 Defect rate: Below 0.1% (by number of screws) Speed: Uniform speed 500mm/s Control unit: Dedicated screw machine control System accuracy: X, Y: ±0.08mm, Z: ±0.05mm Electric screwdriver torque: Adjustable Effective stroke: 500*400*100(X*Y*Z) Alarm items can be customized according to customer requirements: stripped thread, missed screws, thread float (optional) Power source: Stepper motor Transmission method: Precision synchronous belt Operating mode: Front placement/front removal, front placement/rear removal Operating interface: Control card Data communication: USB port export
